Garage Breaker Panel with Conduits from Floor
Photo Details
- Date: March 31, 2026
- Time: 1:27 PM EDT
- Weather: Light rain, overcast, 58°F.
- Phase: Electrical Service Installation
- Location: 309 E. 7th St., Clare, MI — Garage interior, mechanical room area
- View: Looking at breaker panel mounted on wall with conduits rising from floor
Description
The garage 200A breaker panel mounted on the mechanical room wall with two 1” conduits rising up from the floor and entering the bottom of the panel. These two conduits run underground from the house to the garage, entering through the garage floor where they merge from two separate 1” runs into the panel area. This was an unexpected addition to the SLS Electric scope — the owner was not previously aware that separate conduits would be run from the house for wire pulling.
Visible Elements
- Breaker Panel:
- Eaton 200A panel mounted on OSB wall sheathing
- Panel cover installed, breaker positions visible
- Panel appears to be installed but not yet energized
- Mounted in mechanical room area per plan
- Conduits from Floor:
- Two white 1” PVC conduits rising from the concrete slab
- Conduits enter bottom of panel area
- These run underground to house NW corner junction boxes
- Transition from 2x 1” conduits (underground) into panel
- Other Cabling:
- Yellow cable visible at left (likely gas line or other utility)
- Blue cable/tubing visible (possibly network/low-voltage)
- Orange cable coiled at left base (possibly fiber or network)
- Context:
- OSB wall sheathing (unfinished mechanical room)
- Concrete slab floor visible
- Adjacent stud bays visible
- Blue electrical panel cover visible at right edge (possibly future subpanel or disconnect)
Conduit Routing Note
The two 1” conduits from the house are separate from the original 2” PVC utility conduits that were installed through the foundation during the October 2025 pour. The original conduits were for electrical service, gas, water, sewer, and low-voltage. These new 1” conduits provide additional dedicated pathways specifically for wire pulling between the house panel and the garage panel.
